Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 529
abbitt, die cast, and are interchangeable and easilyreplaced. The main bearings of the crank-shaft areprovided with a single groove to take oil under pressurefrom pressure tube which is cast integral with case.Connecting rod bearings are of the same type. Thegudgeon pin is hardened, ground and… … Fig. 237.—Tlie Wisconsin Aviation Engine, at Top, as Viewed fromCarburetor Side. Below, the Exhaust Side. Wisconsin Aviation Engine 531 The bearings of cam-shaft are of bronze. Magneto, twohigh-tension Bosch D. U. 6. The intake manifold forcarburetors are alnminnm castings and are so designedthat…
Airplanes
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
