DrtuewaiJ Fig. 10—PLAN OF MAIN FLOOR at the angles. The stability of the roof depends onthe security with which its plate is spiked at angles,and sheathing nailed to hip rafters. Of course the in-side framing is as ordinarily made, except that insteadof tenoning girths to posts, posts are cut off,… … A NEW YORK BAR.N 19 posts, fish-plates tie them. All bracing is done with twoby eight inch scantling spiked on. See Figure 8. Theground plans, Figures 9 and 10, and elevation here illus-trated are drawn to a scale. The cut showing portion ofrafters is drawn on a much smaller scale. The cost of…
