able slide plates give access to the inside of the boot, front and back. The shaft is 2^& inches with 15-inch travel. The elevator is 196 feet center to center. The boot bearings slide up and down in a cast-iron frame bolted to the boot sides, and carry a slide plate which closes the slot on… … FIG. 271.—Foot of 40-inch Receiving Leg.Public Grain Elevator, New Orleans. (Ford,Bacon & Davis, Engrs.)
