Bench work in wood: a course of study and practice designed for the use of schools and colleges (1902)
Goss, W. F. M. (William Freeman Myrick), 1859-1928 · Boston, Ginn & company · leaf 161
vedby any one of them at points between supports. 146 BENCH WORK IN WOOD. 23O0 Fig. 277 shows Sit A a plain butt-joint, which has ndprovision against opening, and in which the boards do not sup-port each other; it is, really, no joint at all. The same figureshows at B, C, and D, respectively, a… … Joints of this class which have no support outside of them-selves, must be held by glue. 231. A Glued Butt-joint, shown by Fig. 278, if well made,will be quite as strong in the softer woods as a glued matchedor a glued filleted joint. It is difficult, however, especially if theboards are long, to…
Woodwork (Manual training)
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
