-7. Stripes in Solid Black Areas *Three-color black only. C2700 SERIES THERMAL PLOTTER OPERATOR GUIDE 6-7 IN CASE OF DIFFICULTY PLOT MISREGISTRATION Misregistration occurs in color (multipass) plotting when the imagestransferred during each pass do not align correctly with one another.Figure 6-8… … REGISTRATION ERROR = 0.02 in (0.51 mm)*
