Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 235

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 235 — Rectangular Prism or Block 155 90 MECHANICAL DRAWING the elevation. Connecting the points thus obtained gives the endview. End or side views of any object are obtained by projection in this way. Triangular Blockwith Square Hole. Theplan, elevation, and endviews of a triangularblock with a square… … Fig. 123. Projections of a Triangular Prism or Block

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
