Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 262
Fig. 158. Isometric of a WoodenBlock Fig 159. Isometric of a WoodenBrace ^c is drawn; the ellipse is finished by using centers ]i and e. Thisconstruction is applied to all three faces. Cylinder. Fig. 157 is the isometric of a cylinder standingon its base. Blocks. Fig. 158 represents a block with…
Mechanical drawing · Blueprinting
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
