Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 284
L S … I J 129 MECHANICAL DRATaXG the cin uinference at L and Q. With the same radius ?vnd centersand (), draw the arcs cutting the circumference at M and X. The pentagon is completed by drawing the chords E L, L M%MX. NQ, and Q /:. Problem 16. To inscribe aregular hexagon in a given circle. With 0 as a…
