Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 312
either the horizontal or 156 MECHANICAL DRAWING 91 vertical plane of projection. Sometimes it is necessary, however,to draw the views of an object in a position at an angle to the planes.In such case it is usually advisable to draw the object parallel to oneof the planes, and then rotate it to the… … Fig. 125. Plan, Front, and Side Views of a Square Pyramid in size and shape, and the dimensions parallel to this axis on theother planes will remain the same. Pyramid. In Fig. 125, the plan, front, and side views of apyramid are shown, and in Fig. 126 is shown the same pyramidafter it has been…
Mechanical drawing · Blueprinting
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
