Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 434
i^ig. 37. 58 ARCHITECTURAL DRAWING SELF TAUGHT curves are drawn with one radius. The mannerof getting the centers is shown by the dottedlines. Figs. 38 and 39 exhibit another combina-tion of curves which is easy to draw. To makeFig. 39 is perhaps the easiest of them all, as itis formed of curves…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
