Builder's architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Chicago : F.J. Drake & Co. · leaf 79
of an ornamentis in frequentuse in churchwork as the tri-angle is sup-p o s e d to besymbolic of theTrinity. Thestudent shouldcopy this oftenenough so that Fig- 39- … Fig. 40. 60 ARCHITECTURAL DRAWING SELF TAUGHT he can draw or describe it from memoryalone. Fig. 41 is simple enough when the principle isunderstood. The circles inside are drawn from
Architectural drawing
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
