Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 126
Fig. loi. First Floor Plan. This sketch is now a complete plan of the cellar,and one that can be worked to. It will now be in order to draw the first floorplan, as shown in Fig. loi. Proceed the sameas before, only in this case the outer walls aremade \i inch thick, which represents one foot,making… … Fig. 102. Attic Plan. window openings which are represented by three lines running through the openings (j4 i^^chwide^, which is three feet. The two door open- ^ 1 ^ a 1=31 L J C m 3 [ Fig. 103. Front Elevation. ARCHITECTURAL DRAWING SELF TAUGHT PLATE 7. Plate 7 exhibits a portion of cornice and…
Architectural drawing · Architecture, Domestic
