Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 167
Fig. 146. Another style of work is shown at Fig. 146,where the walls are formed of square stones laid 146 ARCHITECTURAL DRAWING SELF TAUGHT … Fig. 147. up in irregular courses, and the relieving archends against a regularly prepared skewback. /ARCHITECTURAL DRAWING SELF TAUGHT 147 At Fig. 147 are grouped some of the principalforms of arch shown in architecture. At A isthe semicircular arch, describing half a circle.B is a form of…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
