62 ARCHITECTURAL DRAWING SELF TAUGHl Suppose AB, Fig. 44, to be the curve, from thepoint A and B strike ares of equal radius inter- … Fig. 43- seating at c and d, and draw a line through theintersections cutting the arc at c. This line will pass through thecenter. Then frompoints € and b, witha rather shorter ra-dius, strike arcs in-tersecting at/and ^,draw a line throughthese intersections,and where the pre-vious line is cut…
