Hicks, I. P. (Isaac Perry), b. 1856 · Omaha, Neb., I.P. Hicks · leaf 57
r: Take 17 inch-es on the blade of a square and one-half 48 THE BUILDERS GUIDE. the rise of the common rafter to a foot runon the tongue and the tougue gives the cut.For example, suppose we have a roof ofone-third pitch. This is a rise of 8 inchesto the foot run. 8 and 12 will make the com-mon… … Fig. 3.
Building
