The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .. (1855)

Leipzig, Dresden : A. H. Payne; [etc., etc.] · leaf 194

An illustration from The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .., 1855, leaf 194
SIDE ELEVATION ARCHES. 93 But the centres may be more readily tbimd by the following- construction, by observingthat the centres must be in a symmetrical position on each side of the rij^ht line CI), whichdivides the right.section into two symmetrical parts. Make Dp equal to l)h, and prolongC D to…
