The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .. (1855)

Leipzig, Dresden : A. H. Payne; [etc., etc.] · leaf 513

An illustration from The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .., 1855, leaf 513
)ly. Figs 6, 7 and 8 are extraordinaryplans; Fig. 6, and particvdarly 7, showing somewhat remark-able dispositions of the steps. (To be continued.) … DESIGN FOR A PAIR OF SEVEN ROOMED VILLAS. PlatesT 110. 117. On the Ground Floor are Hall, Drawing and Dining Rooms, Kitchen, Closets and steps toCellars in Basement. On the Chamber Floor, Three Bed Rooms, Dressing Room and Closet areplaced. The breaks and projecting chinmcys produce a varied effect…

Architecture
