Snelling, Henry Hunt, 1816-1897 · [New York : W.B. Smith] · leaf 16
In the ordinary cameras used by artistsfor sketching, a mirror is introduced whichthrows the image on a semi-transparenttable. Fig. 12 is a section of one form of suchan instrument: a a represents the box, inone end of which is fixed the lens h. The … 12. lenticular image falls on the mirror c,placed at such an angle that it is reflectedon the plane of ground glass d. e is ascreen to prevent the overpowering influ-ence of daylight, which would render thepicture almost invisible. This form of theapparatus, though very interesting as…
Photography · Art and photography
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
