The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .. (1855)

Leipzig, Dresden : A. H. Payne; [etc., etc.] · leaf 566

An illustration from The builder's practical director; or, Buildings for all classes, containing plans, sections and elevations for the erection of cottages, villas, farm buildings, dispensaries, public schools, &c., with detailed estimates, quantities, prices, &c. .., 1855, leaf 566
et or corbel of stone or iron, tailedt least half the thickness of such wall; and of the full breadth of the bressununer. 16. If anv o-utter, formed in i)art or whole of incombustible materials, Pmopets to ex-adjoins an external wall, then such wall must be carried up so as to form aparapet one… … > 17. Every Party ^Vall nuist be carried up above the roof, flat or gutter of the highest building Height of^Partj-adjoining thereto to such height as will give a distance of fifteen inches, measured at right R«°f- angles to the slope of the roof, or fifteen inches above the highestpart of any…
