lso probably benecessary to reinforce thewall by a pilaster, as shownin Figs 477 and 478. If the side wall is aparty wall, or comes closeto the lot line, it will benecessary to convey therain water through soilpipes placed inside thebuilding and a gutter pro-vided at the foot of theskylight to… … Fig. 480. HEA VY FRAMING. 44 i very often necessary to provide for rooms in intermediate stories, 40or 50 feet square, without posts or other vertical supports. If such rooms are not more than50 feet wide the floorabove can be supportedby riveted or trussedgirders, but as the formerare quite…
