Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, Comstock · leaf 718
Fig- 523. Concrete Floor .Slab with Iveinforcing Rods and Spring-lock Bar Spacers. The rods, spacers, etc., shown are made by the manufacturers ofthe Economy unit frame.• 587. PIN-CONNECTED GIRDER FRAME.—Figs. 525 and TYPES OF REIXfORCEMEXTS. 691 526 show the pin-connected girder frame manufactured… … Fig. 524. Rods and .^tool-lock Spacers for Concrete Floor Slabs. and the connections at the columns, and Fig. ^20 shows a sectionthrough reinforced concrete girder and columns with the frameand connections in place.
