dered as the portion sup-ported by the girder. The beams composing the girder in that case,however, should be made very stiff, so as to have little deflection.If there are several openings above the girder, and espcially if thereis a pier over the middle of it, as shown in Fig. 586, then the… … Fig. 585. Amount of Brickwork Supported by Girder. Fig. 586. Onenings over Girder. Amountof Brickwork Supported. as coming on the girder, and proper allowance made for a concen-tration of the greater part of the load at the middle point of thespan. When beams are used to support an entire wall,…
