IiK. :iJO. 200 238 SHEET METAL WORK … the part plan as shown by A B C D E F A, placing the hip or diagonalline F C in a horizontal position; and make the distances between thelines F A and C B and between F E and C D equal, because the roofin this case has equal pitch all around. (The same principles, how-ever, would be used if the…
