Building construction and superintendence (1909)

Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, Comstock · leaf 795

An illustration from Building construction and superintendence, 1909, leaf 795 — and angles, in the manner shown in Fig. 6i6. 644. A\ALL COLUMNS.—The importance of thoroughly fire-■prooting the exterior columns has already been considered in Chap-ter IX. Fig. 616, however, is given as one example of pier con-struction in some Chicago buildings. Further illustrations of the… … Fig. 617. Cast-iron Skewback forBrick Arch.

Building · Carpentry · Masonry
