presented by the arrow, isbetween A and B, and hence is designated as AB. The lower halfof the rafter is designated as AE, and the left half of the tie beamas EO. In the stress diagram, the same letters come at the ends of thecorresponding lines, so that the line ae in the stress diagram showsthe… … (C) Stress Polygon for Joint 5. f StressDiagramXfor Entire Trus^ Nd Fig. 275. small letters to the latter. It does not make any difference whatletters are used but the author finds it convenient to use the firstletters, as A B C, etc., to denote the spaces above the truss, andbetween the forces,…
