Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 295
Stress Diagram.+ Denotes Compression-Denotes Tension … Fig. 301. stress polygons in the order in which the joints are numbered, nojoint has more than two unknown forces, so that there should be nodifficulty with the stress diagram. Problem 26, Fig. 301. Truss like Fig. jj. The stress diagramfor this truss is drawn in the same manner as described in the…
