e cast-iron struts.This truss, being put together entirely withbolts and pins, could easily be erectedwith unskilled labor. 35. TRUSSES FOR FLAT ROOFS.—For supporting flat roofs or roofshaving a fall not exceeding 1 to thefoot, one of the types shown by Figs.80 to 84 will generally be found eco-… … 62 BUILDING CONSTRUCTION. 80 or 81 will answer all practical requirements. The truss shown byFig. 80 is intended to be used where the fall of the roof is at right-angles to the truss; this truss can be built, however, with an incli-nation to the top chord as in Fig. 81. The end brace in Fig. 80…
