a sketch, with the piecesin their proper position and the correct mark placed upon them. Forexample, if it is desired to rivet into place the first panel of the lowerlateral system, the men look on the marking diagram and see thatplates P/j, P/g, and P/g, and the laterals BLl, PL2, and BL3…
