Building construction and superintendence, by F.E. Kidder ... (1896)
Kidder, Frank E. (Frank Eugene), 1859-1905 · New York, W.T. Comstock · leaf 74
and the truss rests on a brick wall oneend of the truss should be supported on rollers to allow for expan-sion and contraction in the steel. The proportions of the trussshown in Fig. 87 are those of the roof trusses of the Jersey Citystation of the Central Railroad of New Jersey. The trusses in… … Fig. 87.—Typical Quadrangular Truss.
