Kidder, Frank E. (Frank Eugene), 1859-1905, Nolan, Thomas, 1857-1926 · New York : W.T. Comstock · leaf 159
commonly used. This gutter isformed by setting a strip of board, i), 3 or 4 inches wide on top ofthe shingles a few inches from the edge of the roof, with brackets. A,placed against it about every 24 inches to keep it in position. TheV-shaped gutter thus formed is lined with tin, which should be… … Fig. 133= Fig- 33- the edge of the board B, and on steep roofs it is better to make thedistance 3 or 4 inches. Fig. 133 shows a similar gutter made entirely of galvanized iron orcopper. Either of these gutters may be placed on any projecting eaves,whether open underneath or boxed in. The only…
Building
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
