in Figs. 501 and 502, a bracket being placed directly overthe removable post. COILING PARTITIONS. 507 Fig. 505 shows a cross section of the transom and coil, shown inFig. 504. One side of the box or transom enclosing the coil shouldbe put up with round-headed screws so as to be removable at will.… … ings within the limits previously given. It is composed of woodslats i^ to 2 inches wide and \ to |-inch thick, fitted together withrule joints edge to edge, and threaded upon tempered steel bandsrunning from top to bottom about 16 inches apart. These bands areriveted to the top bar of the…
