Kidder, Frank E. (Frank Eugene), 1859-1905, Nolan, Thomas, 1857-1926 · New York : W.T. Comstock · leaf 517
Fig 506. -Casing of Coil Box, Vertical FlexifoldPartitions. … Fig. 507. is in an 8-inch partition (6-inch studding), the cheapest method of ar-ranging the coil box and casing the opening, is that shown in Fig. 506,which shows the size of a box for an opening 19 feet wide, closed bya pair of doors. The portion in solid black indicates the coil box. COILING…
Building
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
