Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 542
Fig. 1664.—Enlarged Elevation of Left-hand Jamb of Wood Mantel. Fig. 1661 shows the treatment of an end wallin which a fireplace and doorway occur.Fig. 1666 shows a side wall with a three-lightrecessed window in it. Fig. 1663 gives anenlarged section on line a b (Fig. 1661),showing details of the… … Fig. 1665.—Enlarged Part Section on Line E F(Fig. 1666). Panelled Wainscoting;. trave b, the top portion of the five-panel The wainscoting here shown could be door c, and the framed jamb linings d, executed either in hardwood polished,ror lintel e, framing F, and grounds Q. The top in yellow pine…
Carpentry · Joinery
