art, and are formed of boards as follows:rafters, 2 in. X 8 in.; tie-beams, 2 in. X 10 in.; straps, 2 in. X 6 in. 66 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. The approximalc tost of ihis Ijuuse is alu.ul $! lou tu $1200, and the capacity can be consideredas nearer 600 ihan 500 ions, as… … Fig. 163. — Front Elevation. Fig. 164.—Detail Plan of Walls. R. R., assisted by Mr. F. E. Schnll, shown in Figs. T63 and 164, is a weU-designed frame ice-house, 63ft. X 32 ft. 8 in., out to out, and 32 ft. high from bottom of sill to top of plate. The house is dividedinto two compartments, each 30…
