Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 130
FlG. 210.—LONGITUIIINAL SECTION. OIL-STORAGE HOUSES. 91 cal Engineer, C, B. & Q. R. R., is a two-story brick structure, 20 ft. 8 in. X 19 ft. 4 in., with cellar.The structure is fireproof throughout. The foundations are stone walls. The floor-beams,roof-purlins, and rafters are iron T-beams,… … Fig. 211.—Cross-section.
Railroads -- Buildings and structures · Buildings
