Fig. 263.—Elevation and Cross-section. Fig. 264.—Ground-pi.an. in. to 42 ill. apar:. The floor-beams are supported by 20-in. wrnugln-iron plate-girders on four sidesof the hexagon formed by 6 wrought-iron columns, which transmit the load to a substantial stonefoundation-wall. The floor-beams…
