Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter G. (Walter Gilman), 1858-1908 · New York, J. Wiley & Sons · leaf 238
Fig. 345.—Longitudinal Section. … Fig. 346.- Ground-plan. 200 BUILDINGS AND STRUCTURES OF AMERICAN RAILROADS. clip rag-bolts. The floor is cement on gravel The roof-trusses are very light, Init l)raced bothways, so that the entire structure is very stable. Iron smoke-stacks are inserted at the proper pointsto suit the smoke-stacks…
Railroads -- Buildings and structures · Buildings
