Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 159
Fig. 159.—Cross-section. Fig. 260.—Elevation. ft. deep in the clear, 16 ft. i in. outside diameter at the bottom, and 15 ft. outside diameter at the top.The bottom of the floor of the tank is set 8 ft. 6 in. above the top of rail, and the centre of the tank is UATF.R STATIONS. 123 set about 19 ft.…
Building · Railroads
