Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 146

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 146
the vacuum pipe. R, receiver with a wire screen coveringthe mouth of the draught pipe. S, delivery pipe. O, an air regulator covering the slots inthe end of the suction tube S, to regulatethe proportion of air and grain entering thetube. N, a diaphragm chamber to balance thesleeve O, and controlled… … 345. PNEUMATIC GRAIN ELE-VATOR. French. A high-speed blower re-ceives the grain from a hopper in a regulatedstream through a funnel with sufficient air tomake it semifluid, in which condition it passesthrough the blower and is forced to the desiredelevation. By this method grain is dried andaired,…

Mechanical movements
