Buildings and structures of American railroads. A reference book for railroad managers, superintendents, master mechanics, engineers, architects, and students (1893)
Berg, Walter Gilman, 1858-1908 · New York Wiley · leaf 46
Fig. 22.—Front Ei.rvATiuN.door-studs, 2 in. X 4 in., double; nailing-jiieces, 2 in. X 4 in.; rafters. … M-t.i^— SCALE IN FEET Fig. 23.—End Elevation and Cross-section. Fig. 24.—Ground-plan. Standard Hand-car and Tool-house, Cincinnati Southern Raihcay. - Tht standard hand-car andt-ool-house of the Cincinnati Southern Railway, shown in Figs. 25 to 27, is a frame building,12 ft. X 16 ft. 8 in., with a…
Building · Railroads
