Teachers' manual for freehand drawing in Intermediate schools : intended to accompany the drawing-books for intermediate schools (1878)
Smith, Walter, 1836-1886 · Toronto, A. Miller · leaf 285
e equality -with the other ellipses.As the goblet is supposed to be below the level of the eye, theellipses must be drawn broader as they descend. Make thethickness of the rim at 4 somewhat greater than at 1, sincethe rim at 1 is not only farther from the eye than it is at 4,but is foreshortened… … Egg and Egg-Cup: Fig. 12. DiRECTioys FOK Fio. 12. — Tlie curve next in importanceto tlie ellip.se is the ovoid, or egj^-.shape. It is here shown bythe outline of an egp, a part of which appears above the epg-cnp, Avhile the rest is indicateil by a dotted line in the cup.Draw the central vertical…
Drawing
Internet Archive · University of Toronto Libraries · Public Domain Mark 1.0. Free to use for anything.
