Fig. 1 shows our main bed driving and reversing shaft—a solid steel member (4%n diameter in the larger sizes), madein one piece, the reversing crank and the collar carrying the bed-driving gear being forged integral with the shaft. … Fig. 2 provides an illustration of the shaft with the bed driving gear and crank pin and block in position. This repre-sents a ruggedness of construction neither attained nor attempted in any other flat-bed press. We can give you many other very important and interesting facts in a half-hours…
