Let a (Fig. 9) be the common bracket;draw the parallel lines o o o^io meet the 20 THE carpenters mitre line c; square tip on eacli line atand set the distances 1, 2, 3, 4, (fee, on thecommon bracket, from the line on thesmall lines from c ; through these points, 2,4, 6, &c., trace the form of… … i^lg. 10. Ler a (Fig. 10) be the width of the baseto the cone. Draw the line h through thecentre of the cone; extend the line of theside c till it meets the line & at <^ / on 6? fora centre, with 1 and 2 for a radius, describe HAND-BOOK. 21 which will be the shape of the base re-quired;…
