The carpenter's new guide; a complete book of lines for carpentry and joinery, treating fully on practical geometry, soffits, groins, niches, roofs, and domes, and containing a great variety of original designs. Also a full exemplification of the theory and practice of stair building, cornices, mouldings, and dressings of every description. Including also some observations and calculations on the strength of timber (1854)
with the lower one, H, which completes the falling moulds. To cut the centre or butt joints, divide the distance FE into two equal parts; draw theline H L, and at righ1>angles with this line, draw the lines jP/and E K, which gives thejoints required. To find the Spring of the PlanTc. Fig. 2.… … Plate 56
Carpentry
