The carpenter's new guide; a complete book of lines for carpentry and joinery, treating fully on practical geometry, soffits, groins, niches, roofs, and domes, and containing a great variety of original designs. Also a full exemplification of the theory and practice of stair building, cornices, mouldings, and dressings of every description. Including also some observations and calculations on the strength of timber (1854)
winders. To draw the falling Moulds. Fig. 2. Let A B\)Q the stretch-out of the convex side of the rail, and AI the straightportion attached to the circular part; draw the flyers If and O, and the four winders ODEand F; also draw the hase-line B I, a^t any convenient distance below the point O;…
Carpentry
