The car wheel; giving the results of a series of investigations (1907)

Fowler, George Little, 1855-1926 · Pittsburgh, Pa., Schoen Steel Wheel Co. · leaf 76

An illustration from The car wheel; giving the results of a series of investigations, 1907, leaf 76 — No. 6i. Slag ^s In. Bei o\v Shei lkd-outSroT No. 62. Slag ^ In. Below Shelled outSpot … No 63. Structure yi, In. Below Tread. No. 64. Structure % In. Below Tread. MICROPHOTOGRAPHS OF SHELLED-OUT WHEEL F. 50 DIAMETERS. 71

Railroad cars
