Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 121
Fig. 411.—Trussed Cross Partition Frame with Two Openings and to support Upper Floor. 102 CARPENTRY AND JOINERY. this kind of partition frequently forms the Fig. 413, joints between partition head andsupport of floors, as shown in Fig. 411. It top of door post and strut (see b, Fig. 411).has-been… … Fig 412.—Joint at A (Fig. 411).
Carpentry · Joinery
