Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 138
452 shows the joints and three-wayiron strap at the head of the king-post; alsothe ridge and its junction with the commonrafters. Fig. 453 is the joint at the footof the king-post, with stirrup-iron, gib, andcotters. Fig. 454 is a vertical section-through this joint, showing straps, gibs,and… … CARPENTRY AND JOINERY.
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
