Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 220
The framing j for the smaller dormer is similar to that ! for the larger one ; therefore it has not been with one piece, or smaller sheets may be usedwith rolls, but these are not shown. Thisis an important example, both as regardsroofing and dormers ; but further descriptionis thought unnecessary,… … Fig. 706.—Front Elevation of completed DormerWindow and Junction of Side and Flat. shown in the conventional view, Fig. 700,which is drawn so as to leave exposed someof the main members of the roof. It shouldbe noted that in Figs. 698, 699, and 700 thej masonry is only carried up level with thewall…
Carpentry · Joinery
