Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 226
Fig. 721.—General View of Bracket at Angleand Under Side of Joists, etc. … Fig. 720.—Conventional View showing Principal Joints in Fig. 719 204 CARPENTRY AND JOINERY. therefore the window would have to bebuilt of stone with mullions strong enoughto give the necessary support. The sills(shown as moulded) are supported at the the gable, a moulding being planted on theupper…
Carpentry · Joinery
